Branch Cable

Description

Copper or Aluminum Alloy 8000 Series conductor, with XHHW (90ºC) insulation + Cable Tray Rated PVC jacketed cable, with pre-fab PVC Covered Branch Cable C Connector.
Voltage Rating: up to 600 Volts
Main and Branch Conductor Options:
Copper (Main) + Copper (Branch)
Aluminum (Main) + Aluminum (Branch) 8000 AA

Application

Value Engineering Solution for conventional cable in raceways, multicore, bus ducts
For Power supply units and controller switching equipment with 1.0kV rated voltage and below in low-rise, middle-rise and high rise residential buildings, hotels, hospitals and schools
For lighting systems of roads, bridges, and tunnels

Specification

For Copper
PNS Sizes: Main Conductor Size – (30mm² to 500mm²)
Branch Conductor Size – (5.5mm² to 200mm²)
IEC Sizes: Main Conductor Size – (25mm² to 500mm²)
Branch Conductor Size – (6mm² to 185mm²)

For Aluminum
UL Sizes: Main Conductor Size – (2AWG to 1000MCM)
Branch Conductor Size – (6AWG to 400MCM)
Standard length of Branch Conductor is Three (3) Meters

Features

CABLE STANDARD
• British Standard (BS) 4579, 7889:1997 and 5467:1997
• Japanese Industrial Standards (JIS) C 2810:1995
• International Electrotechnical Commission (IEC) 60502-1, 60228, 60365-5-52
• Insulated Cable Engineers Association (ICEA) S
